Server

Overview​

go logo postgresql logo nats logo

Owlistic server is built using Go, a statically typed, compiled language. The main reason for choosing Go is its strong support for concurrency and efficient memory management, which are crucial for event-driven systems. It also uses the PostgreSQL database for data persistence and NATS as an event streaming system to push real-time updates to clients.

High Level Design​

Owlistic server is implemented following traditional client-server architecture exposing a set of REST APIs for Create, Update, Delete, Read (CRUD) operations. The server exposes a gateway layer for REST APIs responsible for routing requests to the appropriate service.

On top of that, Owlistic leverages event-driven architecture to push updates to an event broker system allowing fast and real-time synchronization. The server exposes a gateway layer for WebSocket connections responsible for pushing events from the downstream broker system to clients.

Following page provides a detailed overview of the server's components and their interactions.

API Routes​

Owlistic server follows Clean Architecture design pattern to expose endpoints for various CRUD operations. The API routing mechanism is based on the Gin web framework, which provides a simple and intuitive way to define routes. Each route is defined using a combination of HTTP methods (GET, POST, PUT, DELETE) and URL paths and leverages core services (controllers) to handle requests and responses and data models (repositories) to handle database interactions.

Clean Architecture

Events Streaming​

Owlistic server uses an Event Driven Architecture (EDA) allowing for real-time updates and communication between services. To enable real-time updates to clients, the server uses outbox design pattern to publish events to clients. This allows for efficient communication between services without the need for polling or long-lived connections.

Outbox Design Pattern

Components​

Core Services​

User Service​

The User Service is responsible for managing user authentication and authorization. Its main responsibilities include:

  • Handling user registration and login requests
  • Authenticating users and verifying their credentials
  • Authorizing users to access specific features and resources based on their roles and permissions
  • Managing user profiles and settings

Notebook Service​

The Notebook Service is responsible for managing notebook entities. Its main responsibilities include:

  • Creating, reading, updating, and deleting notebooks
  • Emitting events on notebook CRUD operations
note

Events emitted by notebook service are persisted as event entities in a database table. At predefined time intervals the event handler service will process events not yet dispatched to forward them to the broker system.

Note Service​

The Note Service is responsible for managing note entities. Its main responsibilities include:

  • Creating, reading, updating, and deleting (CRUD) notes
  • Emitting events on note CRUD operations
note

Events emitted by note service are persisted as event entities in a database table. At predefined time intervals the event handler service will process events not yet dispatched to forward them to the broker system.

Block Service​

Block Service is responsible for managing block entities. Its main responsibilities include:

  • Creating, reading, updating, and deleting (CRUD) block entities
  • Emitting events on block CRUD operations
note

Events emitted by block service are persisted as event entities in a database table. At predefined time intervals the event handler service will process events not yet dispatched to forward them to the broker system.

Task Service​

The Task Service is responsible for managing task entities. Its main responsibilities include:

  • Creating, reading, updating, and deleting tasks
  • Emitting events on task CRUD operations
note

Events emitted by task service are persisted as event entities in a database table. At predefined time intervals the event handler service will process events not yet dispatched to forward them to the broker system.

Event Streaming Services​

Event Handler Service​

The Event Handler Service is responsible for handling events generated by the system. It acts as a producer of un-dispatched event entites and forward them to the broker system. Its main responsibilities include:

  • Processing events created on entitites CRUD operations
  • Dispatching events to event broker system for further processing

WebSocket Service​

The WebSocket Service is responsible for handling WebSocket connections with clients. It acts as a consumer of dispatched event entites and forward them to clients. Its main responsibilities include:

  • Consuming events from all topics
  • Establishing and maintaining WebSocket connections
  • Handling incoming messages from clients
  • Broadcasting messages to connected clients
  • Managing connection states and closing connections as needed

Sync Service​

The Sync Service is responsible for synchronizing data task and block entities. It acts as a consumer of dispatched bloc/task event entites and process them accordingly. Its main responsibilities include:

  • Consuming events from block and task topics
  • Sync task entity on associated block entity changes
  • Sync block entity on associated task entity changes

Event Streaming Components​

Nats​

The event streaming system is based on the NATS messaging system, which allows for efficient and scalable communication between services. Nats is a popular open-source messaging system that enables real-time communication between services. Owlistic server leverages NATS as an event streaming system, allowing for efficient and scalable communication between services.

Producer​

The producer is responsible for publishing events to the event streaming system. It is implemented in producer.go.

  • Responsible for publishing events to the NATS broker.
  • Uses Go's built-in nats library for interacting with NATS.

Consumer​

The consumer is responsible for consuming events from the event streaming system. It is implemented in consumer.go.

  • Represented in code: broker/consumer.go
  • Responsible for subscribing to events published by the producer and handling them accordingly.
  • Uses Go's built-in nats library for interacting with NATS broker.

Data Models​

User Model​

  • Represented in code: models/user.go
  • Description: A user is a entity that can create and interact with notebooks, notes, and tasks.
  • Properties:
    • ID: Unique identifier
    • Email: Email address of the user
    • PasswordHash: Hashed password of the user
    • Username: Username chosen by the user
    • DisplayName: Display name chosen by the user

Notebook​

  • Represented in code: models/notebook.go
  • Description: A notebook is a container for notes.
  • Properties:
    • ID: Unique identifier
    • UserID: Foreign key referencing the user who created it
    • Name: Title of the notebook
    • Description: Brief description of the notebook
    • Notes: List of notes associated with this notebook

Note​

  • Represented in code: models/note.go
  • Description: A note is a container for blocks and tags.
  • Properties:
    • ID: Unique identifier
    • UserID: Foreign key referencing the user who created it
    • NotebookID: Foreign key referencing the notebook that contains it
    • Title: Title of the note
    • Blocks: List of blocks associated with this note
    • Tags: List of tags associated with this note

Block​

  • Represented in code: models/block.go
  • Description: A block is a type of content that can be added to notes.
  • Properties:
    • ID: Unique identifier
    • UserID: Foreign key referencing the user who created it
    • NoteID: Foreign key referencing the note that contains it
    • Type: Type of block (e.g., text, image)
    • Content: The actual content of the block
    • Metadata: Custom metadata set by the user

Task​

  • Represented in code: models/task.go
  • Description: A task is a type of block.
  • Properties:
    • ID: Unique identifier
    • UserID: Foreign key referencing the user who created it
    • NoteID: Foreign key referencing the note that contains it
    • Title: Title of the task
    • Description: Brief description of the task
    • IsCompleted: Flag indicating whether the task is completed
    • DueDate: Due date of the task
    • Metadata: Custom metadata set by the user

Event​

  • Represented in code: models/event.go
  • Description: An event represents an action or occurrence that occurs within the system.
  • Properties:
    • ID: Unique identifier for the event
    • Event: Name of the event (e.g., "note_created", "task_completed")
    • Entity: The entity associated with the event, such as a note or task
    • Timestamp: When the event occurred
    • Data: Additional data related to the event
    • Status: Current status of the event
